TE Connectivity SP1 10kΩ Potentiometer Bracket Mount, SP1-50 | SP1-50

Name: TE Connectivity SP1 10kΩ Potentiometer Bracket Mount, SP1-50 | SP1-50
SKU: 3027-398
Availability: InStock

1 ₫

Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT

Đã bán: 12 pcs

Mfr. Part No: SP1-50

Đánh giá: ⭐⭐⭐⭐⭐

SKU: 3027-398 Categories: Potentiometers, TE Connectivity

Description

Specifications

Attribute	Value
Brand	TE Connectivity
Maximum Resistance	10kΩ
Power Rating	2W
Electrical Taper	Linear
Element Material	Conductive Plastic
Mounting Type	Bracket Mount
Termination Style	Solder
Shaft Length	39.4mm
Travel Length	1270mm
Series	SP1
Tolerance	±10%
Actuator Type	String Pot

Product Details

TE Connectivity SP1 Series Compact String Potentiometers

TE Connectivity’s MEAS SP1 series of string potentiometers offer a compact solution. The small size enables them to be fitted into small spaces, and the mounting bracket permits the user to position the string pot at any angle. These string potentiometers are constructed with a rugged polycarbonate enclosure and provide a linear measurement range of up to 50”/1270mm.

Features and benefits:

• Rugged polycarbonate body
• Included mounting bracket
• Linear position to 50 inches (1270mm)
• Essentially infinite resolution
• Compact to allow for easier mounting in tight spaces
• Free release tolerant measuring cable
• Voltage divider output

Applications:

• Industrial factory automation
• Medical devices
• Structural and automotive testing
• Die casting
• Injection moulding
• Hydraulic cylinder control

What is the advantage of a string potentiometer?

String pots make it extremely easy to measure the position of objects and their position. They can be installed very quickly and with because of their small size, it’s easy enough to mount them in small spaces. Not to mention, they do not require you to have a spot on parallel alignment.
