TE Connectivity Straight 202K1 Black, Modified Polyolefin, 60 mm | 202K174-3-0

Name: TE Connectivity Straight 202K1 Black, Modified Polyolefin, 60 mm | 202K174-3-0
SKU: 8223-817
Availability: InStock

1 ₫

Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT

Đã bán: 10 pcs

Mfr. Part No: 202K174-3-0

Đánh giá: ⭐⭐⭐⭐⭐

SKU: 8223-817 Categories: Heat Shrink Boots, TE Connectivity

Description

Specifications

Attribute	Value
Brand	TE Connectivity
Product Type	Heat Shrink Boot
Sub Type	Straight
Material	Modified Polyolefin
Number of Breakouts	1
Shrink Temperature	90°C
Colour	Black
Minimum Operating Temperature	-55°C
Maximum Operating Temperature	135°C
Maximum Shrunk Diameter	35.1mm
Minimum Inside Diameter	60mm
Minimum Shrunk Diameter	15.7mm
Maximum Inside Diameter	60mm
Standards/Approvals	RoHS
Series	202K1
Adhesive Backing	No

Product Details

General Purpose (Lipped) – 202K1 and 222K1 Series

Moulded parts that provide durable strain relief, protection and an environmental seal when used with an adhesive. Available in straight and right angled types, these chemical and abrasion resistant heat shrink boots are made from a tough modified elastomer, and meet the Def Stan 59-97 Issue 3 Type DE requirements. Other features include recommended shrink temperature 175°C, self-extinguishing to RK6713 and an electric strength of 12MV/m (min.) Meets specification VG95343 parts 6, 7, 8, 9. These boots can be used with spin coupling backshells, but may also be used wherever a connector offers a suitable rear mounting.
