TE Connectivity Surface Accelerometer 2 V 10 V, LCC, 6-Pin | 3038-0050
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 14 pcs
Mfr. Part No: 3038-0050
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | TE Connectivity |
| Sensor Type | Accelerometer |
| Product Type | Accelerometer |
| Technology | MEMS |
| Mount Type | Surface |
| Maximum Frequency Response | 1200Hz |
| Minimum Frequency Response | 0Hz |
| Minimum Supply Voltage | 2V |
| Package Type | LCC |
| Maximum Supply Voltage | 10V |
| Minimum Operating Temperature | -55°C |
| Sensitivity | 0.5mV/g |
| Pin Count | 6 |
| Maximum Operating Temperature | 125°C |
| Series | 3038 |
| Standards/Approvals | NIST traceable calibration |
| Length | 7.5mm |
| Height | 3.3mm |
| Width | 7.5 mm |
| Automotive Standard | No |
Product Details
3038 Series Accelerometer ICs, TE Connectivity
The TE Connectivity 3038 accelerometers are encased within a hermetic LCC package suitable for high performance applications. Long-term stability enabled by the integrated gas-damped piezoresistive element.
Designed for use in harsh environments, suitable applications for these accelerometers include vibration and shock monitoring, embedded applications, instrumentation, machinery and impact testing.
Features and Benefits
• Miniature piezoresistive MEMS
• Hermetically sealed
• Board mountable
• Low power consumption
• 5000 Hz bandwidth
• Mechanical overload provides shock protection to loads greater than 10 kg
Accelerometers, TE Connectivity
