TE Connectivity Surface Sensor 10 V, TDFN, 10-Pin | G-MRCO-048

Name: TE Connectivity Surface Sensor 10 V, TDFN, 10-Pin | G-MRCO-048
SKU: 4629-172
Availability: InStock

1 ₫

Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT

Đã bán: 3 pcs

Mfr. Part No: G-MRCO-048

Đánh giá: ⭐⭐⭐⭐⭐

SKU: 4629-172 Categories: Motion Sensor ICs, TE Connectivity

Description

Specifications

Attribute	Value
Brand	TE Connectivity
Sensor Type	SNTP, IEEE 802.1
Product Type	Sensor
Technology	Magneto Resistive
Mount Type	Surface
Magnetic Type	Anisotropic Magnetoresistive (AMR)
Maximum Supply Voltage	10V
Package Type	TDFN
Minimum Operating Temperature	-40°C
Pin Count	10
Maximum Operating Temperature	150°C
Standards/Approvals	REACH, RoHS
Width	0.75 mm
Length	3mm
Series	G-MRCO
Height	3mm
Automotive Standard	No

Product Details

The TE Connectivity Magnetic field sensor based on the anisotropic magneto resistance effect, that is it is sensing the magnetic field direction independently on the magnetic field strength for applied field strengths. The sensor contains two parallel supplied Wheatstone bridges, which enclose a sensitive angle of 45 degrees. This sensor has contactless angular position which is an ideal for harsh environments with user has complete control over signal evaluation.

High accuracy

Very high resolution

Self diagnosis feature

Low power consumption

Attractive small form factor

REACH and RoHS compliant

Design optimized for linearity
