TE Connectivity Toggle Switch, Panel Mount, On-(On), DPDT, Solder Terminal, 120V | 3-1825138-8
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 5 pcs
Mfr. Part No: 3-1825138-8
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | TE Connectivity |
| Contact Configuration | DPDT |
| Switch Operation | On-(On) |
| Contact Current Rating | 5 A @ 28 V dc |
| Mounting Type | Panel Mount |
| Terminal Type | Solder |
| Panel Cut Out Diameter | 6.35mm |
| Actuator Length | 10.41mm |
| Actuator Material | Phenolic |
| Voltage Rating | 120V |
| Contact Resistance | 0.01Ω |
| Panel Cut Out Size | 6.35mm |
| Contact Material | Silver Plated Copper |
| Minimum Operating Temperature | -30°C |
| Maximum Operating Temperature | +85°C |
| Operating Temperature Range | -30 → +85°C |
Product Details
Panel Mount Toggle Switches – Gemini A Series
Break before make contact timing
Epoxy sealed terminals
Stainless steel frame with brass tin plated solder support
Epoxy sealed terminals
Stainless steel frame with brass tin plated solder support
