TE Connectivity Toggle Switch, Panel Mount, On-On, DPDT, Solder Terminal, 20V | FTN59G04

Name: TE Connectivity Toggle Switch, Panel Mount, On-On, DPDT, Solder Terminal, 20V | FTN59G04
SKU: 7749-461
Availability: InStock

1 ₫

Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT

Đã bán: 12 pcs

Mfr. Part No: FTN59G04

Đánh giá: ⭐⭐⭐⭐⭐

SKU: 7749-461 Categories: TE Connectivity, Toggle Switches

Description

Specifications

Attribute	Value
Brand	TE Connectivity
Contact Configuration	DPDT
Switch Operation	On-On
Contact Current Rating	0.4VA
Mounting Type	Panel Mount
Terminal Type	Solder
Panel Cut Out Diameter	6.2mm
Actuator Length	10.5mm
Actuator Material	Brass
Voltage Rating	20V
Contact Resistance	10mΩ
Contact Material	Gold Plated Copper Alloy
Mechanical Life	100000Cycles
Standards Met	CSA Recognised, RoHS, UL 94V-0
Operating Temperature Range	-20 → +70°C
Minimum Operating Temperature	-20°C
Maximum Operating Temperature	+70°C

Product Details

Toggle Switches, Min, Locking Lever

Switches with a locking lever that is retained in one switch position and may only change over by being drawn out (against a spring retainer) and guided into the other position thus preventing accidental switching
Gold contacts: Stock nos: 317-572 & 317-588
Silver contacts: Stock no: 317-601
Glass Filled Polyester case
