TE Connectivity Toggle Switch, Panel Mount, On-(On), SPDT, Solder Terminal, 125V ac | FTF0904

Name: TE Connectivity Toggle Switch, Panel Mount, On-(On), SPDT, Solder Terminal, 125V ac | FTF0904
SKU: 261-713
Availability: InStock

1 ₫

Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT

Đã bán: 16 pcs

Mfr. Part No: FTF0904

Đánh giá: ⭐⭐⭐⭐⭐

SKU: 261-713 Categories: TE Connectivity, Toggle Switches

Description

Specifications

Attribute	Value
Brand	TE Connectivity
Contact Configuration	SPDT
Switch Operation	On-(On)
Contact Current Rating	4 A @ 30 V dc
Mounting Type	Panel Mount
Terminal Type	Solder
Panel Cut Out Diameter	6.2mm
Actuator Length	10.5mm
Actuator Material	Chrome Plated Brass
Voltage Rating	125 V ac, 250V ac
Contact Material	Fine Silver
Contact Resistance	0.01Ω
Minimum Operating Temperature	-20°C
Maximum Operating Temperature	+80°C
Standards Met	CSA Recognised, RoHS, UL 94V-0
Mechanical Life	100000Operations
Operating Temperature Range	-20 → +80°C

Product Details

Toggle Switches, Min, Professional

Slow make-and-break action
Chrome-plated lever
Solder bucket terminals
A waterproof cover stock no. 321-212 is available (see accessories)
Silver contacts apart from stock nos. 317-077 317-106 317-099 317-112 317-128 and 317-083 which have gold contacts
0.4VA max load
Glass Filled Polyester case
