TE Connectivity White 0.75 mm² Harsh Environment Wire, 0.23 mm, 100m, Polymer Insulation, 100G0111-0.75-9 | 100G0111-0.75-9

Name: TE Connectivity White 0.75 mm² Harsh Environment Wire, 0.23 mm, 100m, Polymer Insulation, 100G0111-0.75-9 | 100G0111-0.75-9
SKU: 9641-442
Availability: InStock

1 ₫

Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT

Đã bán: 4 pcs

Mfr. Part No: 100G0111-0.75-9

Đánh giá: ⭐⭐⭐⭐⭐

SKU: 9641-442 Categories: Hook Up Wire, TE Connectivity

Description

Specifications

Attribute	Value
Brand	TE Connectivity
Cross Sectional Area	0.75 mm²
Sheath Colour	White
Cable Shape	Single Core
Core Strands	0.23 mm
Length	100m
Insulation Material	Polymer
Outer Diameter	1.6mm
Voltage Rating	1.3 kV ac, 750 V ac
Minimum Operating Temperature	-55°C
Maximum Operating Temperature	+125°C
Conductor Material	Tinned Copper
Fire Behaviour	Flame Retardant, Low Smoke Density, Low Smoke Halogen Free (LSZH), Self-extinguishing
Insulation Wall Thickness	0.2mm
Shield Type	Unshielded
Resistant To	Flame, Fluids
Number of Strands	19
Size of Strands	0.23 mm

Product Details

Zerohal Type 100G

100G wire features a dual wall insulation layer manufactured from a TE formulated blend of polymers over tin plated copper conductors. It is designed to meet the requirements of VG95218-20 Type-E while still being lightweight, flexible and resistant to recoil when used for harnessing.

Features & Benefits
• Halogen free, low smoke generation
• Highly flame retardant
• Flexible, easy to install
• Small size, lightweight
• Good fluid resistance
• Non-wrinkling insulation
• Lack of Recoil
