TE Connectivity Zerohal 100G Series Red 0.75 mm² Hook Up Wire, 18 AWG, 19/0.23 mm, 100m, LSZH Insulation, | 100G0111-0.75-2

Name: TE Connectivity Zerohal 100G Series Red 0.75 mm² Hook Up Wire, 18 AWG, 19/0.23 mm, 100m, LSZH Insulation, | 100G0111-0.75-2
SKU: 7488-816
Availability: InStock

1 ₫

Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT

Đã bán: 10 pcs

Mfr. Part No: 100G0111-0.75-2

Đánh giá: ⭐⭐⭐⭐⭐

SKU: 7488-816 Categories: Hook Up Wire, TE Connectivity

Description

Specifications

Attribute	Value
Brand	TE Connectivity
Cross Sectional Area	0.75 mm²
Sheath Colour	Red
American Wire Gauge	18 AWG
Cable Shape	Single Core
Core Strands	19/0.23 mm
Length	100m
Insulation Material	LSZH
Outer Diameter	1.6mm
Voltage Rating	750 V
Maximum Operating Temperature	+125°C
Minimum Operating Temperature	-55°C
Conductor Material	Tinned Copper
Standards Met	DIN-5510-2 Table 6 and Annex C Table C3
Fire Behaviour	Flame Retardant, Low Smoke Density, Low Smoke Halogen Free (LSZH), Self-extinguishing
Series	Zerohal 100G
Number of Strands	19
Size of Strands	0.23 mm

Product Details

Zerohal Type 100G

100G wire features a dual wall insulation layer manufactured from a TE formulated blend of polymers over tin plated copper conductors. It is designed to meet the requirements of VG95218-20 Type-E while still being lightweight, flexible and resistant to recoil when used for harnessing.

Features & Benefits
• Halogen free, low smoke generation
• Highly flame retardant
• Flexible, easy to install
• Small size, lightweight
• Good fluid resistance
• Non-wrinkling insulation
• Lack of Recoil
