Telemecanique Sensors Pressure Sensor, 3.5bar Min, 35bar Max, Relay Output, Differential Reading | XMLB035A2S11

Name: Telemecanique Sensors Pressure Sensor, 3.5bar Min, 35bar Max, Relay Output, Differential Reading | XMLB035A2S11
SKU: 6107-906
Availability: InStock

1 ₫

Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT

Đã bán: 12 pcs

Mfr. Part No: XMLB035A2S11

Đánh giá: ⭐⭐⭐⭐⭐

SKU: 6107-906 Categories: Pressure Sensors, Telemecanique Sensors

Description

Specifications

Attribute	Value
Brand	Telemecanique Sensors
Pressure Reading Type	Differential
Minimum Pressure Reading	3.5bar
Maximum Pressure Reading	35bar
Accuracy	2 %
Output Type	Relay
Media Measured	Air, Fresh Water, Hydraulic Fluid, Sea Water
Process Connection	G1/4
Electrical Connection	PG13.5 Cable Gland
Maximum Current	3 A ac, 100 mA dc
Supply Voltage	120 → 240 V ac, 250 V dc
Housing Material	Zinc Alloy
IP Rating	IP66
Minimum Operating Temperature	-25°C
Maximum Operating Temperature	+70°C

Product Details

OsiSense XMLB Pressure Switches

Schneider Electric XMLB pressure switches for control circuits are used to control the pressure of hydraulic oils, fresh water, sea water, air, steam, corrosive fluids, or viscous products. The XMLB pressure and vacuum switches have an adjustable differential and are for detection of a single threshold.

Adjustable differential
External pressure setting window available
1 NO & 1 NC snap acting contacts
Temperature range: –25 to +70 °C
Enclosure rating: IP65 with plug-in connector, IP66 with terminal connections
Operating rate: up to 120 operations / min. for diaphragm and 60 / min. for piston
Media connection: 1/4″” NPT
Conduit connection: 1/2″” NPT
