Telemecanique Sensors XCS Safety Hinge Switch | XCSPL561
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 9 pcs
Mfr. Part No: XCSPL561
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Telemecanique Sensors |
| Product Type | Safety Hinge Switch |
| Series | XCS |
| Housing Material | Plastic |
| Number of Cable Entries | 1 |
| Terminal Type | Screw Clamp |
| IP Rating | IP67 |
| Cable Entry Size | PG11 |
| Trigger Angle Range | 5 ° |
| Contact Current | 6A |
| Contact DC Voltage | 250V |
| Shaft Length | 72.5mm |
| Contact AC Voltage | 240V |
| Minimum Operating Temperature | -25°C |
| Maximum Operating Temperature | 70°C |
| Height | 88mm |
| Standards/Approvals | UL 508, EN/IEC 60204-1, EN 1088/ISO 14119, EN/IEC 60947-5-1, EN/IEC 60947-5-4, CSA C22.2 No. 14 |
| Width | 103 mm |
| Mechanical Life | 1000000Cycles |
Product Details
XCSPL Safety Hinge Switch
Introducing the XCS PL range of Safety Switches.
As far as safety is involved all dangerous machines in all sectors are involved. Such as packaging, handling, robotics, machine tools, presses and the automotive sector.
Increase productivity thanks to the third contact dedicated to diagnostics.
Head can be oriented in 4 directions
Dimensions: H 60 x W 30 x D 30mm
Operating Temperature -25 to 70°C
Hinge Switch
Standards
EN60947-5-1
