Telemecanique Sensors XCS Safety Hinge Switch | XCSPR551
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 15 pcs
Mfr. Part No: XCSPR551
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Telemecanique Sensors |
| Product Type | Safety Hinge Switch |
| Series | XCS |
| Housing Material | Plastic (Body) |
| Number of Cable Entries | 1 |
| Terminal Type | Screw Clamp |
| Cable Entry Size | PG11 |
| IP Rating | IP67 |
| Trigger Angle Range | 5 ° |
| Contact DC Voltage | 250V |
| Contact AC Voltage | 240V |
| Contact Current | 3A |
| Minimum Operating Temperature | -25°C |
| Shaft Length | 30mm |
| Maximum Operating Temperature | 70°C |
| Width | 30 mm |
| Height | 96mm |
| Standards/Approvals | EN/IEC 60947-5-4, CSA C22.2 No. 14, EN/IEC 60204-1, EN 1088/ISO 14119, UL 508, EN/IEC 60947-5-1 |
| Mechanical Life | 1000000Cycles |
Product Details
XCSPR Safety Hinge Switch
Introducing the XCS PL series.
Ideal for light industrial machines fitted with hinged or rotary protective covers with small opening radius e.g. double gate guards
2 outputs
5° displaced tripping angle
4 position turret head
Ingress protection; IP67
Slow break safety contacts with positive opening operations (positive actuation) N/C contacts open when spindle displaced more than 5°
1 x cable entry tapped for 11mm cable gland, ISO M16 x 1.5 or ½ NPT
Hinge Switch
