Telemecanique Sensors XCS Safety Hinge Switch | XCSTR752
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 6 pcs
Mfr. Part No: XCSTR752
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Telemecanique Sensors |
| Product Type | Safety Hinge Switch |
| Series | XCS |
| Housing Material | Plastic |
| Number of Cable Entries | 2 |
| Terminal Type | Screw Clamp |
| IP Rating | IP67 |
| Cable Entry Size | M16 x 1.5 |
| Trigger Angle Range | 5 ° |
| Minimum Operating Temperature | -25°C |
| Contact DC Voltage | 250V dc |
| Contact Current | 3A |
| Contact AC Voltage | 240V ac |
| Shaft Length | 30mm |
| Maximum Operating Temperature | 70°C |
| Width | 52 mm |
| Height | 117mm |
| Length | 80mm |
| Standards/Approvals | EN/IEC 60947-5-1, EN/IEC 60947-5-4, EN 1088/ISO 14119, EN/IEC 60204-1, UL 508, CSA C22.2 No. 14 |
| Mechanical Life | 1000000Cycles |
Product Details
XCS TR, Hinge
Ideal for light industrial machines fitted with hinged or rotary protective covers with small opening radius e.g. double gate guards
3 outputs
5° displaced tripping angle
4 position turret head
Ingress protection; IP67
Slow break safety contacts with positive opening operations (positive actuation) N/C contacts open when spindle displaced more than 5°
2 x cable entries tapped for 11mm cable gland, ISO M16 x 1.5 or ½ NPT
Hinge Switch
