Time Electronics Resistance Decade Box 0.01 Ω | 1051

Name: Time Electronics Resistance Decade Box 0.01 Ω | 1051
SKU: 465-966
Availability: InStock

1 ₫

Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT

Đã bán: 16 pcs

Mfr. Part No: 1051

Đánh giá: ⭐⭐⭐⭐⭐

SKU: 465-966 Categories: Decade Boxes, Time Electronics

Description

Specifications

Attribute	Value
Brand	Time Electronics
Decade Box Type	Resistance
Product Type	Decade Box
Accuracy	±0.1 %
Number of Decades	8
Decade Test Range	0 to 1 MΩ
Height	75mm
Length	110mm
Width	200 mm
Weight	600g
Standards/Approvals	BS EN 61340-5-1:2007, ANSI/ESD S20.20:2014
Resolution	0.01 Ω
Calibrated	UKAS

Product Details

Time Electronic Resistance Decade Box

The Time Electronic resistance decade box is a compact, durable, housed in a robust metal case with a removable protective rubber cover. It is designed to meet the requirements of both, industry and education. Its excellent accuracy (mid-scale 0.1%) is achieved by using high stability metal film resistors. Its 8-digit thumbwheel switch enables simple and precise setting with an indication of the resistance value.

Features and Benefits

Resistance measurement ranges between 0.01ohm and 1Mohm

Clear visual indication

High accuracy

High stability

Low-temperature coefficient

Power rating is 1W

Resistance resolution is 0.01ohms

Safety terminals

Applications

Industrial use

Laboratory work

Certifications

ANSI/ESD S20.20:2014

BS EN 61340-5-1:2007

Document Download

1051 Decade Resistance Box Technical Manual
1051 Low Ohm Resistance Box Data Sheet
