Trumeter 722 Hour Meter, 6 Digit Analogue, 50Hz, 90 → 264 V ac | 722-0001
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 5 pcs
Mfr. Part No: 722-0001
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Trumeter |
| Supply Voltage | 90 → 264 V ac |
| Count Mode | Hours |
| Display Type | Analogue |
| Input Type | Voltage |
| Function | Hour Meter |
| Connection Type | Spade Terminal |
| Reset Method | No Reset |
| Number of Digits | 6 |
| Mounting Type | Panel Mount |
| Output / Interface | Voltage |
| Digit Height | 3.6 mm |
| Maximum Count Frequency | 50 Hz, 60Hz |
| Cutout Size | 36.8 x 24.1 mm |
| Series | 722 |
| Measurement Range | 0 → 99999.9h |
| Cutout Width | 36.8mm |
| Depth | 48mm |
| Meter Type | Electromechanical |
| Minimum Operating Temperature | -40°C |
| Cutout Height | 24.1mm |
| Minimum Measurement | 0h |
| Meter Accuracy | ±0.02% |
| Approvals | 12 Compliant, CE, cUL, NEMA 4x, RoHS Compliant, SAE, UL |
Product Details
Trumeter 722 Series Hour Meters
The 722 series of Hour Meters have an operating range of 9-264V ac 50/60Hz. Models are available in the standard industry housings and are quartz time based to ensure accurate long-term time keeping. The totally sealed cases of these Hour Meters protects against the environment and provides years of reliable service.
6 Figures 3.6mm high
Operating voltage 90-264V ac
Totally sealed
Non-reset
Clip or mounting holes
Quartz accuracy
Minimum 36 second on-time for event capture
NEMA 4x rated
Operating voltage 90-264V ac
Totally sealed
Non-reset
Clip or mounting holes
Quartz accuracy
Minimum 36 second on-time for event capture
NEMA 4x rated
