Trumeter APM-MAX LCD Digital Panel Multifunction Meter for Process Meter or a Shunt Meter, 68 mm x 68 mm | APM-MAX-M23-NU-4B

The APM-MAX-M23 is a multi-function panel meter designed for lower voltage applications. It is configurable as an process meter or to measure 0–50mA DC direct, or 0-500mV DC in conjunction with a shunt.

The unique display combines the instant visual representation of analogue with the accuracy of digital for instant recognition and precision measurement. It has a 25% larger screen than our standard APM, incorporating a 60-segment bar graph display, large 4 digit display, separate Starburst display area for messages and alarm info and a full colour RGB dynamic backlight for instant alerts.

Programmable Scaling and Range (min and max), annunciators, backlight colour and intensity, two independent alarm set-points, two independent digital outputs, a 4-20mA analogue output and serial MODBUS® TCP/IP and RTU for communication with other components in a system as well as an IP65 rating.

The negative display, for darker environments where high contrast is required, features colour changing figures on a black background.

• Fully user-configurable digital panel meter

• Dynamic full-colour, RGB backlight for endless configuration options

• 81.5mm x 66mm screen – 25% larger than the standard APM

• Remote monitoring with Trumeter Cloud when used with Trumeter IoT Gateway

• 0.5% Voltage Accuracy, 0.1% frequency accuracy

• Modbus RTU / TCP IP included for seamless integration

• 2 independent outputs: 2 digital (open collector), 1 analogue (4 – 20mA)

• 108mm x 108mm, 64mm deep, fits 2.7in square, or 4in diameter circular cutout

• 60-Segment bar graph display

• Large, high contrast, anti-glare, LCD display with wide viewing angle

• Starburst display area for messages and alarm information

• Scaling and range options including min. and max, offset and gain, centre zero, 20 point non-linearization scaling, and more

• 2 alarm setpoints

All Trumeter products come with a 3-year manufacturer’s warranty
