Specifications
| Attribute | Value |
|---|---|
| Brand | Trumeter |
| Supply Voltage | 3.6 V Battery |
| Count Mode | Impulses |
| Display Type | LCD |
| Function | Counter |
| Input Type | Logic, Voltage |
| Connection Type | Terminal |
| Reset Method | Electrical |
| Number of Digits | 8 |
| Mounting Type | Panel Mount |
| Output / Interface | Pulse |
| Count Direction | Bi-Directional |
| Digit Height | 9 mm |
| Backlighting | Yes |
| Maximum Count Frequency | 10kHz |
| Display Range | 0 → 99999999 |
| Maximum Temperature | +60°C |
| Weight | 62g |
| Measurement Range | 0 → 99999999 |
| Minimum Operating Temperature | -10°C |
| Maximum Operating Temperature | +60°C |
Product Details
Trumeter Digital Counter
Note
Backlight requires an external supply
All Trumeter products come with a 3-year manufacturer’s warranty
Features and Benefits
External reset input
Front reset function can be disabled to prevent accidental or un-approved resetting
Provides the user with a viable alternative to an electro-mechanical counter
Contact closure/open collector low speed count input with integral de-bounce circuitry
Choice of mounting available, front panel with supplied bezel or rear mounting clip
Operation temperature ranges between -10°C and 60°C
Applications
Position, length, rotation, and distance measuring
Certifications
UL approved
cUL approved
IP65 rated
