Trumeter Digital Power Meter AC/DC | VT-PWR-LV

The Trumeter Vista Touch Power (LV) is designed for single, split, and 3-phase applications, offering precise measurement of Active (W), Reactive (Var), and Apparent (VA) power with 1% accuracy across the input range. This Low Voltage model is compatible with 12-24VAC/DC power supply units.

The Vista Touch instantly unlocks your data with the powerful remote monitoring platform, Trumeter Cloud. Monitor your reading anytime, anywhere with your free subscription, and receive data recording along with online, SMS, and email alerts. With a vibrant HD graphical display (70mm x 70mm (2.76″ x 2.76″)), the device offers simple, intuitive touchscreen configuration, user-programmable scales, custom alarm messages, and advanced alarm notifications. It provides clear indication of electrical circuit performance and features programmable Current Transformer (CT) and Potential Transformer (PT) ratios.

The Vista Touch Power supports Modbus® RTU and TCP, comes with Ethernet and RS485 as standard as well as two form C relays. Users can load and save configuration data to a USB flash drive, and it uses industry-standard ¼ DIN mounting with modular pluggable quick connect/disconnect connectors.

• For single, split and 3 phase applications

• Measures Active (W) Reactive (Var) and Apparent (VA) power

• 1% accuracy across the input range

• Programmable Current Transformer (CT) and Potential Transformer (PT) ratios

• Free access to the IoT Trumeter Cloud remote monitoring, with SMS and email alarm notifications

• 2 x form C relay

• 65K colour 70mm x 70mm [2.76″ x 2.76″] graphics display

• Intuitive touchscreen navigation and configuration

• User programmable scale, custom alarms and messages

• Load and save configuration via USB flash drive

• Modbus® RTU and TCP

• Industry standard ¼ DIN mounting

• Ethernet and RS485 as standard

• Modular pluggable quick connect/disconnect connectors

All Trumeter products come with a 3-year manufacturer’s warranty
