Turck Inductive Block Proximity Sensor, M8, 5 mm Detection, PNP NO, 10 → 30 V dc | BI5U-Q08-AP6X2-V1131
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 6 pcs
Mfr. Part No: BI5U-Q08-AP6X2-V1131
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Turck |
| Thread Size | M8 |
| Sensor Technology | Inductive |
| Body Style | Block |
| Detection Range | 5 mm |
| Digital Switching Output Type | PNP |
| Output Function | NO |
| Connection Type | M8 |
| Supply Voltage | 10 → 30 V dc |
| Length | 32mm |
| IP Rating | IP67 |
| Mounting Type | Flush |
| Housing Material | Gadolinium Zinc |
| Width | 20mm |
| Maximum DC Voltage | 30V |
| Minimum Operating Temperature | -30°C |
| Maximum Switching Frequency | 250Hz |
| Depth | 8mm |
| Shielding | Unshielded |
| Switching Current | 200 mA |
| Switching Frequency | 250 Hz |
| Short Circuit Overload Protection | Yes |
| Maximum Operating Temperature | +85°C |
| Reverse Polarity Protection | Yes |
Product Details
Turck Proximity Sensor, Gadolinium Zinc Housing, IP67 – BI5U-Q08-AP6X2-V1131
This Turck proximity sensor in block style is designed to offer reliable and accurate detection capabilities for various industrial applications. With a detection range of 5mm and IP67 rating, this sensor is suitable for use in challenging environments.
Features & Benefits
• Equipped with PNP output type for seamless integration into existing systems
• Flush mount design for easy installation in tight spaces
• Constructed with Gadolinium Zinc housing material for durability and reliability
• Offers short circuit overload protection for enhanced safety
• Flush mount design for easy installation in tight spaces
• Constructed with Gadolinium Zinc housing material for durability and reliability
• Offers short circuit overload protection for enhanced safety
Applications
• Suitable for automated machinery in manufacturing plants
• Ideal for use in conveyor systems for object detection
• can be used for robotics applications for precise sensing capabilities
• Ideal for use in conveyor systems for object detection
• can be used for robotics applications for precise sensing capabilities
Can it withstand high temperatures?
It operates efficiently in temperatures ranging from -30 °C to +85 °C.
Will it provide reliable detection in challenging environments?
Yes, the IP67 rated sensor is designed to perform accurately in harsh conditions.
Is the installation process easy?
The flush mount design makes installation quick and straightforward.
Uprox Range
Extended sensing ranges
Sense all metals at the same distance – with no reduction factor
IP67 rating (Barrel is IP68)
High switching frequency
No load current 15mA max.
Operating Temperature Range -25 → +85°C
Short circuit protection Overload protection
Reverse polarity protection
Inherent weld field immunity
Sense all metals at the same distance – with no reduction factor
IP67 rating (Barrel is IP68)
High switching frequency
No load current 15mA max.
Operating Temperature Range -25 → +85°C
Short circuit protection Overload protection
Reverse polarity protection
Inherent weld field immunity
