Wachendorff, 29 mm OD Flexible Coupling | DSK290606

Wachendorff, 29 mm OD Flexible Coupling | DSK290606

1 ₫

Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT

Đã bán: 11 pcs

Mfr. Part No: DSK290606

Đánh giá: ⭐⭐⭐⭐⭐

SKU: 3837-582 Categories: ,

Specifications

Attribute Value
Brand Wachendorff
Product Type Flexible Coupling
Outside Diameter 29 mm
Maximum Speed 3.000rpm
Torque Rating 50Ncm

Product Details

The double loop coupling is designed for encoders with shaft Ø 6 mm, providing smooth running and maintenance-free operation. With good resistance to various chemicals, this coupling is ideal for applications requiring precise torque transmission.

Designed for encoder with shaft Ø 6 mm

No moving parts, smooth running, and maintenance-free operation

Good resistance to gasoline, oil, benzene, and various chemicals

maximum operating speed of 3.000 rpm

maximum torque of 50 Ncm

maximum offset of shafts radial ± 2.0 mm

maximum offset of shafts axial ± 2.0 mm

maximum offset of shafts angular ± 10°

Torsion spring stiffness of 13 Nm/rad

Radial spring stiffness of 13 N/mm

Moment of inertia of 41 gcm²

maximum clamping torque of 100 Ncm

Operating temperature range of -30 °C up to +80 °C

Weight of 33 g

Material flange made of steel galvanized, connecting element made of polyurethane

Document Download

Datasheet – DSK290606
