WIKA Panel Mount PID Temperature Controller, 64mm Relay, 12 → 24 V ac, 16 → 36 V dc Supply Voltage | 14054709

Name: WIKA Panel Mount PID Temperature Controller, 64mm Relay, 12 → 24 V ac, 16 → 36 V dc Supply Voltage | 14054709
SKU: 8003-261
Availability: InStock

1 ₫

Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT

Đã bán: 5 pcs

Mfr. Part No: 14054709

Đánh giá: ⭐⭐⭐⭐⭐

SKU: 8003-261 Categories: Temperature Controllers, WIKA

Description

Specifications

Attribute	Value
Brand	WIKA
Output Type	Relay
Supply Voltage	12 → 24 V ac, 16 → 36 V dc
Size	64mm
Minimum Operating Temperature	0°C
Maximum Operating Temperature	+50°C
Temperature Range	-50 → +130 °C, -80 → +400 °C
Display Type	Single 3 Digit 7-Segment LED Display
IP Rating	IP00, IP65
Input Type	PT100, PT1000, PTC
Mounting Type	Panel Mount
Display Colour	Red
Panel Depth	50mm
Termination Type	Faston

Product Details

The model SC64 is a temperature controller for simple thermostat applications. It features simple operation and a high switch rating. Its round case enables the instrument also to be used in applications where mechanical controllers were used so far. In addition, the SC64 can handle significantly more switching cycles.

Temperature controller and digital indicator in a single instrument
Long service life
Simple operation
High contact rating, up to 12 A
For panel mounting
